Application

The Circular Rubbing Color Fastness Tester evaluates friction damage and surface color transfer on colored materials. It is suitable for testing upper materials such as leather, plastic, and fabric in various industrial applications.

Working Principles

The test runs under constant pressure conditions, rubbing dry or wet circular wool felt against the sample. The machine stops automatically after completing the preset rubbing count. Operators then determine color fastness by checking the sample surface and rubbing pad for color transfer. Results are assessed using a standard gray scale to ensure accuracy and consistency.

Standards

BS EN 13516 Method B, SATRA PM8, QB/T 1619-2018 annex B, ISO 17700 Method B

Features

The Rub Fastness Tester performs multiple test methods, including dry rubbing, wet rubbing, perspiration rubbing, alcohol rubbing, and organic liquid rubbing. (Note: Customers need to prepare the test liquids themselves.)
The counter allows users to preset the number of test cycles and displays the actual test count. The machine automatically stops once the preset count is reached.
Its memory function saves the current test count if the operator stops the test manually before completion. The count remains stored until reset to zero or the test continues. However, when the machine is shut down and restarted, the count resets to zero while the preset value remains unchanged.
The Rotary Rubbing Fastness Tester can apply different loads according to the specific testing requirements.

Specification

Revolution of rubbing axis: 150±5 r/min
Load: 7.1 ± 0.2 N or 24.5 ± 0.5 N
Wool felt: External diameter: 25±1mm; Inner diameter: 3±0.5mm
Aluminum plate: Diameter: 50mm; Thickness: 12mm
Metal plate: 75mm×65mm×5mm (L×W×D); diameter of bore center: 25mm
Power Supply: 1∮AC220V 50/60HZ
Dimensions (LxWxH): 28 ×43 ×47 cm
Weight: 35 kg

Why Choose Circular Rubbing Color Fastness Tester

Choose the Circular Rubbing Color Fastness Tester for its precision, versatility, and efficiency in color fastness testing. It supports multiple testing modes—dry, wet, alcohol, perspiration, and organic liquid rubbing—to meet a wide range of industrial standards including ISO 17700 and BS EN 13516. Its automatic counting and memory functions allow seamless operation and accurate tracking of test cycles, even during interruptions. The durable construction and adjustable load feature ensure consistent, repeatable results across different material types. Whether for laboratory or quality control use, this tester provides dependable performance, helping manufacturers maintain high product standards and prevent color transfer issues in production.
