Yarn Appearance Board Winder

The Yarn Appearance Board Winder is a precision textile testing instrument used to evaluate yarn appearance, evenness, and defects by winding yarn onto standard black boards. Yarn Appearance Board Winder features a rugged steel body with an ergonomically designed table-top structure for stable operation. The motorized mechanism with stepped pulley and traversing motion ensures uniform winding with selectable yarn spacing. Automatic left-direction wrapping with a preset stopper minimizes manual interference, while variable speed allows testing of fine to coarse yarn counts. Compatible with both rectangular and tapered boards, it supports multiple ends-per-inch standards. Ideal for textile laboratories and quality control departments to visually assess yarn quality and consistency.

Features

Ergonomically designed table top model having rugged steel body construction.
Motorized and precision-engineered Mechanism for smooth and accurate Operation.
Choices of wide range of rectangular and tapered winding black boards.
Operating under stepped pulley mechanism with traversing motion ensures uniform winding in different pitch as per standards.
Automatic wrapping in left directions with pre-settable stopper eliminates manual disturbances.
Variable winding speed option for fine to course count of yarn.
Yarn wrapped on the board can be 20, 22, 26, 32, 38 & 48 ends per inch.
Specially designed yarn bobbin stands for precise sampling.

Technical Data

Measuring range: 1’s to 135’s Count (NeC)
Tapered board size: 305 x 280 x 178 mm (or) 22 x 11 x 7 inch
Rectangular board size: 280 x 178 mm (or) 11 x 7 inch
Standard Yarn Spacing: 20, 22, 26, 32, 38 & 48 ends per inch (or) 8, 9,10, 13, 15 & 19 Per Cm
Power supply: Single phase 220vAC @ 50Hz
Consumption: 50 watts
Applicable Standard(s): ASTM D2255 and IS 13260
Physical Dimensions: Size (WDH): 72 x 55 x 42 cm
Weight: 32 kg

Scope of Supply

Main Unit – 1 No.
Accessories: Yarn bobbin stand – 1 No., Transmission Belt – 1 No., Mains cord – 1 No.,
Spares: Glass fuse (1A) – 3 Nos.
2 Nos of tapered and rectangular board each (black Board)
Documents: User’s guide, Warranty certificate, Test certificate & Calibration certificate.
