Dishwasher Resistance Testing Machine

The Dishwasher Resistance Testing Machine is designed for evaluating the mechanical dishwashing resistance of appliances under automatic cycle conditions. It complies with EN 12875-1 and related standards to ensure accurate, repeatable, and professional test results.

Technical Specifications

• Independent Design: Based on the domestic Midea dishwasher model.
• Dimensions: 700 × 700 × 850 mm.
• Capacity: 13 sets (Midea dishwasher P60).
• Hot Water: Heats up to 70°C. The machine includes a soft water module and real-time monitoring data.
• Water Spray Pressure: 29,000 Pa.
• Cycle Temperature Control: PLC + touch screen.
• Dosing Mechanism: Automatic dosing by weight, using a vibration plate with a weighing system. A precision weighing sensor is installed on the top of the dishwasher. The system also includes a water filter and real-time water quality monitoring.
• Dosing Range: Adjustable between 0–30 g via touchscreen.
• Test Cycles:
  • Mode 1: Standard EN 12875-1 Article 8.3.
  • Mode 2: Custom settings.

Test Cycle Stages (EN 12875-1 Article 8.3)

• Drain: Empty the dishwasher with a water pump.
• Pre-Wash: Fill the dishwasher with water, circulate for 5±0.5 minutes, then drain.
• Wash:
  • Fill with 6.0±0.5 L of water and 24±3 g cleaning agent per liter.
  • Heat to 60±2°C and circulate for 20±1 minutes.
  • Continue circulation for 3±1 minutes without heating.

• Rinse:

  • Add fresh water.
  • Circulate for 3±0.5 minutes.
  • Drain the system.

• Final Wash:

  • Refill with water.
  • Heat circulating water to 65±2°C.
  • Maintain 40–45°C and add 2.5–3.0 g bleach per 6.0±0.5 L of water.
  • Pump circulation continues at 65±2°C.

• Drying: Store samples inside. Keep the door closed for 3±1 minutes, then open for 30±1 minutes.

Performance Features

• Real-time water softening module controls hardness (Ca/Mg) between 0.3–0.6 mmol/L, tested per ISO 6059.
• Fixed water quantity of 6.0±0.5 L for each test. Water pressure ranges from 5 N/cm² to 100 N/cm² (pump lift 0.3–0.4 MPa).
• Accurate detergent and bleach dosing system for every cycle.
• Automatic door actuation and cycle repetition for reliability.
• Customizable programs: users can adjust heating temperature up to 80°C.
• Automatic alarms after each cycle and at the end of set test runs.
• Reports: Export raw data or reports via USB. Reports include cycle times, temperature, and water softening records.

Construction and Safety

• Stainless steel main body for durability.
• Leakproof bottom tray with drainage pipe to prevent water damage.
• Door design ensures stability and spray protection; spray stops automatically if the door remains open.
• Basket design supports heavy cookware:
  • Upper basket up to 10 kg.
  • Lower basket up to 20 kg.

Safety compliance: EN 60335-1 and EN 60335-2-5.

• Includes backup consumables for easy replacement.

Why Choose the Dishwasher Resistance Testing Machine?

The Dishwasher Resistance Testing Machine is essential for manufacturers ensuring appliance durability. Since mechanical resistance is critical for dishwasher longevity, this machine provides accurate testing per EN 12875-1 standards, simulating real-world cycles. For example, it tests water quality and heating consistency, identifying potential failures in hinges or seals. Its customizable features and safety measures, like leakproof trays, enhance reliability and user safety. Consequently, producers can improve product quality and comply with safety regulations. For more details or to request a demo, contact our team today.
