Softness Tester is a new type of high-precision intelligent tester carefully and rationally designed with modern mechanical design concepts and microcomputer processing technology. It is an ideal experimental equipment for industries and departments such as papermaking, scientific research and quality inspection.

Standards

GB/T 8942 QB/T 1060 TAPPI T 498 cm-85

Application Range

Toilet paper, tobacco sheets
Fabrics, non-woven fabrics
Fabrics, films, etc.

Application Function

Measuring softness

Product Features

One-click test, easy to understand
ARM processor improves the response speed of the instrument, calculates data accurately and quickly
Real-time display of pressure curve
Sudden power failure data saving function, the data before the power failure is retained after the power is turned on and the test can be continued
Software and hardware over-range to ensure the safety of the sensor
Communication with computer software (purchase separately)

Key Technical Parameters

Standards: GB/T 8942, QB/T 1060, TAPPI T 498 cm-85
Application Range: Toilet paper, tobacco sheets, fabrics, non-woven fabrics, films
Power Supply: AC 100–240V, 50/60Hz, 50W
Working Environment: (10–35)℃, Humidity ≤85%
Display: 7-inch color touch screen
Measuring Range: 10–1000mN
Indication Resolution: 0.1mN
Indication Error: ±1% (5%–100% range)
Total Probe Stroke: 12±0.5mm (adjustable)
Probe Indentation Depth: 8mm
Test Speed: 1.2±0.012mm/s (72±0.72mm/min, 1–250mm/min adjustable)
Specimen Table Gap Width: 5/6.35/10/20mm (four gears adjustable)
Slit Parallelism Error: ≤0.05mm
Probe Centering Error: ≤0.05mm
Print: Built-in thermal printer
Communication Interface: RS232 (USB, WIFI optional)
Dimension: 425 x 290 x 300mm
Net Weight: Approx. 20kg

Optional accessories (Purchase separately)

RS232 interface and computer software: 1 set

Why Choose the Softness Tester?

The Softness Tester ensures accurate softness measurement with its high-precision design and real-time data display. Its compliance with TAPPI T 498 cm-85 and compact 20kg build make it a top choice for textile and paper industries.
