NBS Rubber Abrasion Tester Overview

The NBS Rubber Abrasion Tester is a specialized device designed to determine the resistance to abrasion of vulcanized rubber or other compounds used for the soles and heels of footwear. This Tester operates by placing a test piece on the machine, applying a specific load, and rotating it against sandpaper to assess its wear resistance. It is not recommended for materials thinner than 2.54 mm (0.1 in.). For more information, please Contact with AdLab

Principle

Place test piece on the test machine, add a certain load in order to rotate rubbing specimen of sandpaper, and check its readability.

Feature of the Rubber Abrasion

It is equipped with three dials, allowing users to set the prewear thickness before testing begins.
The tester features LCD control, which automatically stops the test once the set parameters are met, ensuring precision.
It includes a vacuum cleaner to clear wear powder in real-time, maintaining a clean testing environment and ensuring accurate results.
The machine supports testing of up to three specimens simultaneously, improving efficiency in high-volume testing scenarios.
Control mode – LCD control

Key Specification

Model: ADL-AT03
Number of Specimens: 3 pieces
Wheel Diameter: 150 mm
Specimen Size: 25.4 x 25.4 x 6 mm
Load: 22 N (approximately 2265g)
Sandpaper: Grit 40#
Rotary Speed: 45 ± 5 rpm
Counter: LCD, 0 – 99,999
Vacuum Cleaner Pressure: Average pressure of 4kg/cm²
Power Supply: 1∮ AC 220V 50/60Hz 3A
Dimensions (L x W x H): 720 x 460 x 580 mm
Weight: 105 kg
Standard Accessories: Hose clamp (3 pcs), weights (3 pcs), power line (1 pc)
Optional Accessories: P40# sandpaper, pre-wear rubber, standard rubber

Why Choose the NBS Rubber Abrasion Tester?

The NBS Rubber Abrasion Tester is an essential tool for footwear manufacturers aiming to ensure the durability of soles and heels. Since abrasion resistance is a critical factor in determining the lifespan of footwear, this tester provides accurate measurements by simulating wear conditions with sandpaper and a specified load. For instance, it is ideal for testing vulcanized rubber or other compounds, ensuring they meet industry standards like ASTM D1630 and SATRA TM 221. Moreover, its automated features, such as LCD control and a vacuum cleaner for debris removal, make it highly efficient for quality control. Consequently, manufacturers can improve product longevity and meet customer expectations. For more details on how this equipment can enhance your testing process, please Contact with AdLab
